Satech Machinery Pvt Ltd is trusted and reliable Manufacturer, Exporter and Supplier of 175 mm Bandsaw Machine in Punjab.
Our Manufacturing unit is based in Ahmedabad, Gujarat, India.
S Mech SM 708 is designed for precision cutting across diverse materials and industries.
Engineered for durability, accuracy, and user-friendliness, the SM 708 is ideal for workshops, fabrication units, and manufacturing facilities seeking efficient, reliable cutting solutions.
About Satech Machinery Pvt Ltd
• Over 32+ years of industry experience
• 3 manufacturing plants
• 5,000+ machines installed globally
• 60+ machines produced monthly
• Commitment to 100% quality-tested products
• Dedicated customer support and expert guidance
Standard Accessories
• Electric Motor (1 HP, 1440 RPM)
• Coolant Pump (0.15 HP, 2800 RPM)
• ON-OFF Push Button
• Job Stopper
• M42 HSS Bi-Metal Blade
• Swarf Cleaning Brush
• Tool Kit
Optional Accessories
• Material Roller Stand
• Manual Material Feeder
• Foot Lifting Pedal
Technical Specifications
| MODEL | SM 708 |
|---|---|
| Cutting Cap. – Round (mm) | Ø175 MM |
| Cutting Cap. – Square (mm) | 200 x 100 MM |
| Motor | 1 HP, 1440 RPM |
| Coolant Pump | 0.15 HP, 2800 RPM |
| Drive | WORM GEARBOX |
| V-Belt Size | B30 |
| Blade Size (mm) | 2540 x 27 x 0.9 MM |
| Blade Speed (mtr/min) | 33-52-77 MTR/MIN |
| Weight (Kg) | 330 KG |
| Dimensions L x W x H (mm) | 1450 x 1000 x 1050 MM |
Work Principle of S Mech SM 708 Manual Bandsaw Machine
1. The manual bandsaw uses a continuous band blade that runs over two wheels.
2. The workpiece is securely clamped on the table or vice.
3. The operator manually feeds the workpiece towards the moving blade.
4. The blade cuts through the material by a sawing action as it moves continuously.
5. The blade’s teeth remove material layer by layer during each pass.
6. The cutting speed and pressure depend on the operator’s control.
7. The saw blade’s tension and alignment are maintained for smooth cutting.
Features of S Mech SM 708 Manual Bandsaw Machine
• High precision, smooth, and fast cutting operations
• Capable of cutting various metals: non-ferrous metals, steel, stainless steel, tool steel, die steel, etc.
• Suitable for cutting multiple profiles: round, square, hexagonal bars, pipes, I-beams, angles, channels
• Easy hydraulic feed control for accurate cuts
• Low noise operation ensuring a better working environment
• Automatic coolant pump with saw on/off.
• Automatic machine turn-off at the end of the cut to save power and enhance safety
• Robust worm gearbox with bronze casted worm gear and hardened worm shaft for long service life
• Heavy-duty, vibration-free design for stability during operation
• Chrome-plated vice components for enhanced durability
• Spring tension system to adjust the saw arm weight for optimal cutting pressure
Typical Uses
• Cutting metals in fabrication shops and manufacturing plants
• Processing structural steel sections like I-beams, angles, and channels
• Precision cutting of stainless steel, tool steel, and die steel components
• Versatile cutting for any metal and any section.
• Ideal for maintenance and repair operations in industrial settings
Frequently Asked Questions (FAQs)
Q1: What materials can the SM 708 cut?
A1: The SM 708 can cut a wide range of materials including ferrous and non-ferrous metals. It can cut brass, copper, aluminum, mild steel, stainless steel, tool steel, die steel etc.
Q2: How does the machine ensure operator safety?
A2: The SM 708 includes blade guards, an emergency stop button, and automatic turn-off at the end of the cut to maintain a safe working environment.
Q3: Is the machine suitable for heavy industrial use?
A3: Yes, with its robust worm gearbox, heavy-duty construction, and vibration-free design, the SM 708 is built for continuous industrial operation.
Q4: What optional accessories are available?
A4: Optional accessories include a material roller stand, manual material feeder, and foot lifting pedal to enhance ease of operation.
Satech Machinery Pvt Ltd is Supplier of 175 mm Bandsaw Machine in Punjab including locations Ludhiana, Amritsar, Jalandhar, Patiala, Bathinda, Mohali, Moga, Batala,
Pathankot, Ferozpur, Abohar, Malerkotla, Khanna, Phagwara, Kapurthala, Rajpura, Muktsar, Hoshiarpur, Faridkot, Barnala, Mukerian and many more.
For more information, pricing, or to request a quote on the SM 708 Manual Bandsaw Machine, please contact our expert team.
