Satech Machinery Pvt Ltd is a trusted Manufacturer, Exporter and Supplier of Light Duty ALL Geared Lathe Machine in Maharashtra.
Our Headquartered in Kuha, Ahmedabad, Gujarat, India.
The SGL1 Light Duty All Geared Lathe Machine from Satech Machinery Pvt Ltd is expertly engineered to provide high precision, operational efficiency, and lasting
durability
for a variety of machining tasks.
Trusted by Maharashtra workshops, this model suits light to medium industrial use with smooth operation and low maintenance.
Satech has grown into a reputed manufacturer and supplier of high-performance lathe machines, milling machines, and other industrial tools.
The Light Duty All Geared Lathe Machine is a popular product known for reliability, durability, and efficiency in metalworking.
Introduction to Light Duty All Geared Lathe Machine
A Light Duty All Geared Lathe Machine is designed for precision turning, facing, threading, drilling, and boring operations on smaller or lighter workpieces.
Unlike traditional belt-driven lathes, this machine uses an all-geared transmission system, offering superior torque and speed control.
This type of lathe is ideal for tool rooms, maintenance workshops, educational institutions, and small-scale industries.
Satech’s model is built with robust materials and high-grade components to ensure smooth operation, minimal maintenance, and accurate results over time.
Why Choose the SGL1 Model from Satech Machinery?
• Precision-Crafted for Performance
The SGL1 lathe, built with precision, delivers accurate turning performance and consistent surface finishes for quality machining.
• All-Geared Drive System
Provides enhanced smoothness and control in machining with multiple speed settings to efficiently handle various materials.
• Durable Build Quality
Constructed using high-grade cast iron, offering a stable structure with reduced vibrations for precise results.
• Ideal for Light-Duty Industrial Use
Perfectly suited for workshops, tool rooms, and training institutes that require compact yet capable machinery.
Features of SGL1 Lathe Machine:
• High-tensile steel spindle ensures strength and long service life.
• Induction-hardened lathe bed delivers a rigid, vibration-free work surface.
• Versatile thread cutting – Supports metric, inch, and module thread options.
• Smooth and accurate tailstock alignment enhances machining accuracy.
• Compact design with ergonomic lever and knob placement for ease of use.
• High surface finish and dimensional precision in all turning operations.
• Taper roller bearing-supported spindle for enhanced stability and performance.
Standard Accessories Provided
• Flame-hardened bed ways
• Chuck back plate – 1 no
• Center adapter
• 2 Dead Centers (MT-3)
• Tool post spanner
• Motor pulley with V-belts
• Change gear set for both metric and inch threads (includes Norton gearbox)
• Thread dial indicator
Optional Accessories Available
• Face plate
• Carrier plate
• Steady rest
• Follow rest
• Taper turning attachment
• Motorized coolant pump with tank and fittings
• Rear tool post with extended cross slide
• Chuck back plate
• Complete electrical kit (Motor, Panel board, wiring, push-button switches, splash guard)
Technical Specifications – SGL1 Model
Specification : Details
Admit Between Centers : 660 mm
Length of Bed : 1370 mm (4′-6″)
Floor Space Occupied : 1500 mm x 850 mm
Approx. Weight : 550 kg
Center Height Over Bed : 165 mm
Swing Over Bed : 325 mm
Swing Over Cross Slide : 175 mm
Swing in Gap : 500 mm
Width of Bed : 240 mm
Spindle Bore : 38 mm
Spindle Nose Type : Threaded
Spindle Taper : MT-5
Spindle Adapter Taper : MT-3
Spindle RPM Range : 8 Speeds: 54 – 1200 RPM
Spindle Mounting : Taper roller bearings
Spindle Diameter / Travel : 38.1 mm / 120 mm
Leading Screw Diameter / Threads : 25.4 mm / 4 TPI
Thread Cutting – Metric : 17 types: 0.5 mm to 15 mm pitch
Thread Cutting – Inch (Norton Gearbox) : 40 types: 2 to 60 TPI
Applications of Light Duty All Geared Lathe Machine
• Precision Turning
• Thread Cutting
• Drilling & Boring
• Facing & Chamfering
• Prototyping & R&D
FAQs:
Q1: What makes an All Geared Lathe better than a belt-driven lathe?
A: All Geared Lathes offer superior torque, smooth operation, and precise speed control for perfect precision work.
Q2: Is the machine suitable for beginners or students?
A: Training centers and educational institutes prefer Satech’s light duty models for their safety and user-friendly interface.
Q3: What materials can be machined using this lathe?
A: It is suitable for a wide range of metals, including mild steel, aluminum, brass, and copper.
Q4: Does Satech provide installation and training?
A: Yes, Satech Machinery offers complete installation, setup, and operational training for their lathe machines.
Q5: What is the maintenance requirement?
A: Regular lubrication and cleaning, along with periodic inspection of gears and bearings, ensure long life and consistent performance.
Satech Machinery Pvt Ltd is a Supplier of Light Duty ALL Geared Lathe Machine in Maharashtra including locations in Mumbai, Pune, Nagpur, Thane, Pimpri-Chinchwad,
Nashik, Kalyan-Dombivli, Vasai-Virar, Aurangabad, Navi Mumbai, Solapur, Mira-Bhayandar, Bhiwandi-Nizampur, Jalgaon, Amravati, Nanded-Waghala, Kolhapur, Ulhasnagar,
Sangli, Malegaon, Akola, Latur, Dhule, Ahmednagar, Chandrapur, Parbhani, Ichalkaranji, Jalna, Ambarnath, Bhusawal, Panvel, Badlapur, Beed, Gondia, Satara, Barshi, Yavatmal,
Achalpur, Osmanabad, Nandurbar, Wardha, Udgir, Hinganghat and many more.
Contact us today for customized solutions, pricing, and expert guidance.
