Every fabrication shop eventually meets the same problem: large bars and thick sections that slow production and waste material.
The S-Mech SMSA 600 Semi-Automatic Bandsaw Machine from Satech Machinery Pvt. Ltd., a trusted bandsaw manufacturer in Ahmedabad, Gujarat, with 32 years of experience, is built for that work.
It cuts solid rounds up to 600 mm and square sections up to 425 x 425 mm. Its hydraulic vice, hydraulic feed control and automatic cycle give you repeatable, clean cuts without constant operator effort.
Why Choose the SMSA 600 Semi-Automatic Bandsaw?
• Cuts a wide range of metals: copper, brass, aluminium, mild steel, alloy steel, stainless steel and tool steel.
• Cuts different profiles: round, flat, angle, channel and pipe.
• Hydraulic vice: holds the workpiece firmly, which improves cutting accuracy and safety.
• Hydraulic feed control: gives precise, smooth blade feed.
• Bi-metal blade: gives faster, smoother and more accurate cutting.
• Automatic cycle: the machine switches off at the end of the cut, and the saw arm lifts automatically.
• Chrome-plated guide units: adjustable, for blade stability.
• Spring tension on the saw arm: adjusts the arm load for different sizes and types of metal.
• Auto-operated coolant pump: keeps blade and job cool and extends blade life.
• Low-noise operation: more comfortable for operators.
• 6-month warranty against manufacturing defects.
SMSA 600 Technical Specifications
Parameter Specification
Model SMSA 600
Cutting Capacity, Round 600 mm
Cutting Capacity, Square 425 x 425 mm
Drive Motor 5 HP, 960 RPM
Hydraulic Motor 1 HP, 1440 RPM
Coolant Pump 0.15 HP, 2800 RPM
Drive Worm gearbox
V-Belt Size B68
Blade Size 5800 x 41 x 1.3 mm
Blade Speed 22 / 37 / 55 / 75 m/min
Weight 1520 kg
Dimensions (L x W x H) 3650 x 1070 x 1370 mm
Standard and Optional Accessories
Standard: electric motor, coolant pump, job stopper, M42 HSS bi-metal blade, swarf cleaning brush and tool kit.
Optional: material roller stand, bi-metal HSS bandsaw blade, manual bar feeding mechanism with worm gear, and degree cutting fixture.
Industries and Applications
The SMSA 600 suits structural steel, pipes and profile cutting in metal fabrication shops. It is also used in manufacturing units and by automotive, aerospace and construction industries for custom cutting.
Why Satech Machinery Pvt. Ltd.?
Satech manufactures pivot-type and double-column LMG bandsaw machines in manual, semi-automatic and fully automatic configurations.
Each machine comes with installation, training and after-sales support, so your team gets full value from the equipment.
FAQs: SMSA 600 Semi-Automatic Bandsaw Machine
Q1: What is the maximum cutting capacity of the SMSA 600?
A1: It cuts round bars up to 600 mm and square sections up to 425 x 425 mm.
Q2: Which materials can the SMSA 600 cut?
A2: It cuts copper, brass, aluminium, mild steel, alloy steel, stainless steel and tool steel. It handles round, flat, angle, channel and pipe sections.
Q3: What makes it “semi-automatic”?
A3: The machine switches off automatically at the end of the cut, and the saw arm lifts on its own. A hydraulic vice and hydraulic feed control reduce manual work.
Q4: What motor power and blade speeds does it have?
A4: It has a 5 HP drive motor, a 1 HP hydraulic motor and a 0.15 HP coolant pump. Blade speeds are 22, 37, 55 and 75 m/min.
Q5: What blade size does the SMSA 600 use?
A5: It uses a bi-metal blade of 5800 x 41 x 1.3 mm. An M42 HSS bi-metal blade is supplied as standard.
Q6: Is there a warranty and after-sales support?
A6: Yes. The machine carries a 6-month warranty against manufacturing defects. Satech also provides installation, training and maintenance support.
We Supply 600 mm Semi-Automatic Bandsaw Machine in Rajasthan including locations Jaipur, Jodhpur, Pali, Tonk, Udaipur, Alwar, Sikar, Balotra, Bikaner, Ajmer, Kota, Sri Ganganagar, Bhilwara, Banswara,
Bharatpur, Baran, Beawar, Bhiwadi, Hanumangarh, Dholpur, Pratapgarh, Dungarpur, Jaisalmer, Hindaun, Bundi, Chittorgarh, Kishangarh, Sujangarh, Sawai Madhopur, Pushkar, Churu.
Request your SMSA 600 quote today and let Satech Machinery turn every cut into faster profit.
