Double Column Bandsaw Machine Manufacturer in Ahmedabad: SSL 200 Semi-Automatic LMG Model
Satech Machinery Pvt. Ltd. is a trusted manufacturer and supplier of bandsaw machines in Ahmedabad, Gujarat, with 32 years of experience.
Our S-Mech SSL 200 Semi-Automatic LMG Bandsaw Machine is built for fabrication units, workshops and industrial plants that need accurate, repeatable and economical cutting of ferrous and non-ferrous metals.
What Is the 200mm Double Column Bandsaw Machine?
• A semi-automatic, double column (LMG) horizontal bandsaw for cutting round and square metal stock.
• Hydraulic operation of the vice and saw arm, with manual bar feeding.
• Cuts Ø200 mm round and 200 x 200 mm square material.
• Suited to small bars as well as large stock.
Features of the SSL 200 Bandsaw Machine:
• Semi-Automatic Operation: Hydraulic vice and saw arm movement reduce operator effort.
• High-Precision Cutting: Accurate cuts on ferrous and non-ferrous materials.
• Robust, Heavy-Duty Frame: Gives stability and reduced vibration for long-lasting performance.
• Variable Frequency Drive (VFD): Convenient blade speed control from 20 to 85 m/min.
• Hydraulic Feed Control: Smooth, consistent blade feed for uniform cuts.
• Optimum Blade Life: Gets the most cutting life from each bandsaw blade.
• Easy Blade Replacement: Quick, safe blade changes that cut downtime.
Technical Specifications:
| Parameter | SSL 200 (Semi-Auto) |
|---|---|
| Cutting Capacity (Round) | Ø200 mm |
| Cutting Capacity (Square) | 200 x 200 mm |
| Saw Motor | 2 HP, 1440 RPM |
| Hydraulic Motor | 1 HP, 1440 RPM |
| Coolant Pump | 0.15 HP, 2800 RPM |
| Drive | Worm Gearbox |
| Blade Size | 3000 x 27 x 0.9 mm |
| Blade Speed | 20–75 m/min (VFD) |
| Approx. Weight | 850 kg |
| Dimensions (L x B x H) | 1550 x 1320 x 1380 mm |
Industries and Applications:
• Fabrication and engineering workshops
• Steel and metal stockists
• Automobile and auto-component units
• Machine building and tool rooms
• General industrial manufacturing
• Cutting of bars, rods, pipes and solid sections in steel and non-ferrous metals
Frequently Asked Questions (FAQs):
Q1: What is the cutting capacity of the SSL 200 bandsaw machine?
A1: It cuts up to Ø200 mm round and 200 x 200 mm square material.
Q2: What is a double column LMG bandsaw machine?
A2: It is a horizontal bandsaw whose saw frame moves on two LM rails mounted on two vertical columns. This gives more rigidity and more accurate cuts than a pivot design.
Q3: Is the SSL 200 fully automatic?
A3: No, it is semi-automatic. The vice and saw arm movement are hydraulic, while bar feeding is manual.
Q4: What is the blade speed range, and can it be adjusted?
A4: Blade speed runs from 20 to 75 m/min and is adjusted through the VFD.
Q5: Which materials can the SSL 200 cut?
A5: It cuts a wide range of ferrous and non-ferrous metals in round and square sections.
We Supply Double Column Bandsaw Machine in West Bengal including locations Kolkata, Asansol, Siliguri, Durgapur, Bardhaman, Malda, Baharampur, Habra, Kharagpur, Shantipur, Dankuni, Dhulian, Ranaghat, Haldia, Raiganj, Krishnanagar, Nabadwip, Medinipur, Jalpaiguri, Balurghat, Basirhat, Bankura, Chakdaha, Darjeeling, Alipurduar, Purulia, Jangipur, Bolpur, Bangaon.
Get your SSL 200 quote and upgrade to faster, cleaner, more profitable metal cutting with Satech.
