Satech Machinery Pvt. Ltd. manufactures the S Tech SMSA 325 Semi Automatic Bandsaw Machine for accurate and efficient metal cutting.
Designed for workshops, fabrication units and industrial production facilities, this hydraulic bandsaw machine delivers smooth cuts across round, square and structural metal sections.
Our machine can process materials ranging from soft non-ferrous metals to hard tool steels. Its hydraulic vice, controlled saw-arm movement, multiple blade speeds and M42 HSS
bi-metal blade support reliable cutting with reduced operator effort.
Our Manufacturing unit is based in Ahmedabad, Gujarat, India.
Features of the 325 mm Semi Automatic Bandsaw Machine
- High cutting capacity: Cuts round materials up to 325 mm and square sections up to 250 × 250 mm.
- Hydraulic vice clamping: Holds the workpiece firmly to improve stability and cutting accuracy.
- Controlled hydraulic feed: Allows precise adjustment of the saw-arm feed for different materials and sizes.
- Automatic saw-arm movement: The arm rises automatically after completing the cutting cycle.
- Automatic machine turn-off: Stops the machine at the end of the cut for safer, more convenient operation.
- Four blade-speed options: Speeds of 22, 37, 55 and 75 m/min accommodate materials with varying hardness.
- M42 HSS bi-metal blade: Supports faster cutting, smoother finishes and consistent dimensional accuracy.
- Adjustable blade guides: Chrome-plated guide units help maintain stable blade alignment during operation.
- Worm gearbox drive: Provides dependable power transmission for continuous industrial cutting.
- Adjustable spring tension: Helps operators set the saw-arm load according to the workpiece profile and material.
- Automatic coolant circulation: Reduces cutting heat and supports blade performance and service life.
- Swarf-cleaning brush: Removes metal chips from the blade during operation.
- Low-noise performance: Suitable for workshops seeking efficient operation with controlled noise levels.
- Six-month warranty: Covered against manufacturing defects for six months, subject to applicable warranty terms.
Standard Machine Accessories
Ou Bandsaw Machine is supplied with essential accessories for convenient operation and dependable cutting:
- Electric motor
- Automatic coolant pump
- Job stopper
- M42 HSS bi-metal bandsaw blade
- Swarf-cleaning brush
- Tool kit
Optional Accessories
Optional equipment can be selected according to the material-handling and cutting requirements of
your facility:
- Material roller stand
- Bi-metal HSS bandsaw blade
- Manual bar-feeding mechanism with worm gear
- Degree-cutting fixture
Metals Suitable for Cutting
Hydraulic Semi Automatic Bandsaw Machine is engineered to cut metals with different hardness levels, including:
- Copper
- Brass
- Aluminium
- Mild steel
- Alloy steel
- Stainless steel
- Tool steel
Selecting the appropriate blade, blade speed and feed pressure helps produce clean cuts while supporting longer blade life.
Sections and Profiles the Machine Can Cut
This semi automatic horizontal bandsaw machine can cut a variety of solid and hollow workpieces:
- Round bars
- Flat bars
- Square sections
- Angles
- Channels
- Pipes and tubes
- Structural metal profiles
Benefits for Industrial Metal-Cutting Operations
The SMSA 325 combines hydraulic control with a practical semi automatic operating cycle. After the material is positioned and clamped, the machine controls the cutting feed,
turn off at the end of the cut and automatically raises the saw arm.
Its major operational benefits include:
- Reduced operator effort
- Consistent cutting across repeated jobs
- Secure holding of heavy workpieces
- Accurate cutting of multiple metal profiles
- Improved surface finish
- Controlled blade feed and cutting pressure
- Efficient coolant delivery
- Simple operation and routine maintenance
- Suitability for low-volume and regular production work
Applications of the Bandsaw Machine
The SMSA 325 is suitable for metal-cutting requirements across:
- Engineering workshops
- Steel fabrication units
- Machine-building facilities
- Tool rooms
- Maintenance departments
- Automotive component plants
- Stainless-steel processing units
- Metal stockholding businesses
- Structural fabrication facilities
- General manufacturing plants
Frequently Asked Questions
Q1. What is the maximum round cutting capacity?
A1. The SMSA 325 can cut round workpieces up to 325 mm in diameter.
Q2. What square material size can the machine cut?
A2. It can cut square sections measuring up to 250 × 250 mm.
Q3. Can the machine cut stainless steel?
Q3. Yes. With the correct blade speed and feed setting, it can cut stainless steel and other hard metals.
Q4. Which bandsaw blade does the machine use?
A4. It uses an M42 HSS bi-metal blade measuring 3760 × 27 × 0.9 mm.
Q5. Does the saw arm rise automatically?
Q5. Yes. The saw arm automatically rises after the cutting cycle is completed.
Q6. Is the machine covered by a warranty?
Q6. Yes. It includes a six-month warranty against manufacturing defects, subject to the applicable terms.
