Satech Machinery Pvt. Ltd. is a trusted Semi Automatic Bandsaw Machine Supplier offering practical metal-cutting solutions for engineering, fabrication, and industrial applications.
Designed for controlled and repeatable cutting, these machines help manufacturers improve productivity while reducing manual effort.
The S-Mech 225mm semi automatic bandsaw machine combines operator control with automated cutting functions. The operator positions and secures the workpiece, while the machine performs the cutting cycle with controlled blade movement.
- Accurate Cutting: Maintains consistent cutting dimensions across production batches.
- Reduced Manual Effort: Automates major cutting operations after material loading.
- Better Productivity: Supports faster material preparation for downstream processes.
- Controlled Operation: Helps maintain steady blade movement and cutting performance.
- Industrial Construction: Suitable for demanding workshop and manufacturing environments.
Why Choose a Semi Automatic Bandsaw Machine?
Businesses looking for reliable metal-cutting equipment can use semi automatic bandsaws to balance productivity, flexibility, and operator involvement.
- Suitable for MS, stainless steel, alloy steel, and other metal sections.
- Handles repetitive cutting requirements with greater consistency.
- Helps reduce material preparation time.
- Supports fabrication, engineering, automotive, and general manufacturing applications.
- Provides a practical solution where fully automatic cutting is not necessary.
Technical Specifications – SMSA 912
| Specification | Details |
|---|---|
| Model | SMSA 912 |
| Cutting Capacity (Round) | Ø225 mm |
| Cutting Capacity (Flat) | 150 × 300 mm |
| Drive Motor | 1 HP, 1440 RPM |
| Hydraulic Motor | 1 HP, 1440 RPM |
| Coolant Pump | 0.15 HP, 2800 RPM |
| Drive | Worm Gearbox |
| V-Belt Size | B33 |
| Blade Size | 3000 × 27 × 0.9 mm |
| Blade Speed | 37–52–70 m/min |
| Weight | 460 kg |
| Dimensions (L × W × H) | 1600 × 1000 × 1100 mm |
Features of Semi Automatic Bandsaw Machine
- Semi automatic cutting operation
- Hydraulic controlled blade feed
- Variable blade speed for different materials
- Robust machine frame for industrial use
- Adjustable cutting parameters
- Coolant system for improved blade life
- Easy workpiece loading and positioning
- Consistent straight cutting performance
- Operator-friendly controls
- Suitable for batch production
Applications of Semi Automatic Bandsaw Machine
Semi automatic bandsaw machines are useful across industries where accurate metal section cutting is a regular production requirement.
Fabrication Units
Cutting pipes, channels, angles, and structural sections.
Engineering Industries
Preparing metal components for machining and assembly.
Automotive Manufacturing
Cutting bars, tubes, and other metal components.
Machine Manufacturing
Preparing raw material before turning, milling, or drilling.
Steel Processing
Cutting metal sections into required lengths.
Maintenance Workshops
Handling occasional and repetitive metal-cutting jobs.
How Does a Semi Automatic Bandsaw Machine Work?
The machine follows a controlled sequence to simplify repetitive cutting operations:
- Material Loading: The operator places the metal section on the machine bed.
- Workpiece Clamping: The material is securely held to minimise movement.
- Cutting Setup: The operator selects suitable blade speed and cutting parameters.
- Blade Operation: The bandsaw blade moves continuously through the material.
- Controlled Cutting: The machine maintains steady cutting movement.
- Completion: Once the cut is finished, the operator removes the processed material.
Frequently Asked Questions
Q1: What is a semi automatic bandsaw machine?
A semi automatic bandsaw machine is a metal-cutting machine that automates the cutting cycle while requiring an operator for loading, positioning, and setup.
Q2: What materials can a semi automatic bandsaw cut?
It can be used for various metals, including mild steel, stainless steel, alloy steel, carbon steel, nickel alloys, die steel, and tool steel.
Q3: Is a semi automatic bandsaw suitable for high production?
Yes. It is suitable for repetitive cutting applications where consistent dimensions and controlled production are required.
Q4: What industries use semi automatic bandsaw machines?
Engineering, fabrication, automotive, steel processing, machine manufacturing, and general industrial workshops commonly use these machines.
Q5: How does it reduce manual work?
Once the material is correctly positioned and the cutting parameters are set, the machine performs the main cutting operation automatically.
Semi Automatic Bandsaw Machine Supplier in Maharashtra
We supply Semi Automatic Bandsaw Machines in Maharashtra, including: Mumbai, Pune, Nagpur, Thane, Pimpri-Chinchwad, Nashik, Kalyan-Dombivli, Vasai-Virar, Aurangabad, Navi Mumbai, Solapur, Mira-Bhayandar,
Bhiwandi-Nizampur, Jalgaon, Amravati, Nanded-Waghala, Kolhapur, Ulhasnagar, Sangli, Malegaon, Akola, Latur, Dhule, Ahmednagar, Chandrapur, Parbhani, Ichalkaranji, Jalna, Ambarnath, Bhusawal, Panvel, Badlapur, Beed,
Gondia, Satara, Barshi, Yavatmal, Achalpur, Osmanabad, Nandurbar, Wardha, Udgir, Hinganghat.
Choose Satech Machinery for Semi Automatic Bandsaw Machines
Choose Satech Machinery for dependable semi automatic bandsaw solutions that improve cutting accuracy, productivity, and industrial efficiency.
